Gorila G40S I PRO CAB Mini Excavator

Gorila G40S I PRO CAB
Location: Hořice, Czech Republic

Machine Overview:
Gorila G40S I PRO CAB tracked mini excavator with 4 t operating weight, YANMAR 3TNV88F engine and cab equipment for professional excavation work. The machine is supplied with multiple buckets and attachments listed in the source details.

Key Features:
- 4 t operating weight
- YANMAR 3TNV88F engine
- 24 hp power output
- Zero tail swing
- Cab with air conditioning, heating, LCD display and radio
- Joystick control
- Bucket digging force: 30 kN
- Maximum digging depth: 3165 mm

Technical Data
Engine:
- Engine: YANMAR 3TNV88F
- Rated power: 18,2 / 2200
- Power output: 24 hp
- Fuel tank capacity: 41 L

Hydraulic System:
- Hydraulic pump model: LX10V045 / HP5V45
- Maximum flow: 99 L/min
- Working pressure: 26 / 25,5 MPa
- Hydraulic tank capacity: 50 L

Work Area:
- Bucket volume: 0,12 m³
- Max. digging height: 4920 mm
- Max. dumping height: 3490 mm
- Max. digging depth: 3165 mm
- Max. digging reach: 5260 mm
- Max. digging reach at ground level: 5135 mm

Dimensions / Transport:
- Length: 4,8 m
- Width: 1,74 m
- Height: 2,48 m
- Overall length: 4800 mm
- Overall width: 1740 mm
- Overall height to cab roof: 2480 mm
- Arm length: 1,37 m

Undercarriage:
- Track width: 1740 mm
- Track shoe width: 300 mm
- Track contact length with ground: 1660 mm
- Track length: 2120 mm

Attachments & Equipment:
- Bucket 350 mm
- Bucket with teeth 550 mm
- Hydraulic slope bucket 1200 mm
- Hydraulic quick coupler controlled from the cab
- Earth auger
- Ripper tooth
- Rake and grapple
- Quick couplings, pins, hoses, toolbox, tools and grease gun
