2024 Thaler 3448 H DPF Mini Excavator

Thaler 3448 H DPF
Location: Rittersdorf, Germany

Machine Overview:
2024 Thaler 3448 H DPF loader with hydrostatic all-wheel drive, oscillating rear axle and Stage V DOC and DPF emissions equipment. The machine has 2,5 t lifting capacity, 3,86 m lift height and 25 km/h max speed.

Key Features:
- 2024 manufacture year
- 2,5 t lifting capacity
- 3,86 m lift height
- 25 km/h max speed
- Hydrostatic all-wheel drive
- 4-cylinder Yanmar diesel engine
- Working hydraulics max. 51 l/min.
- Euro mount with hydraulic locking

Technical Data

Engine:
- Power output: 36 hp
- 4-cylinder Yanmar diesel engine
- Water-cooled, 35,4 KW (48PS) at 3000 U/min.
- DOC and DPF emission standard Stage V

Hydraulic System:
- Working hydraulics max. 51 l/min.
- 3rd control circuit on joystick function(LiftLower) with mech. single-sided detent
- Fully hydraulic articulated steering with 2 DW steering cylinders
- Gear pump 20 ccm clockwise rotation

Work Area:
- Lifting capacity: 2,5 t
- Lift height: 3,86 m

Dimensions / Transport:
- Width: 1,48 m
- Max speed: 25 km/h

Undercarriage:
- Rear tires: bkt 31-15,5-15
- Wide tyres 31-15,5-15 BKT SKD
- Self-locking differential 40 %
- Oscillating axle at the rear

Attachments & Equipment:
- Euro mount
- Hydraulic locking via control unit
- Standard lighting incl. 3 work lights 2x front 1x rear top
- Road-compliant lighting STVZO
- Removable beacon
- Fops-Rops roof
- Comfort seat air-suspended with seat heating
- Towing device
