2023 Kobelco SK80UR-6E Mini Excavator

Kobelco SK80UR-6E | 8 t | 2000 hours
Location: Shanghai, China | Availability: 5 units available
Machine Overview:
2023 Kobelco SK80UR-6E 7-ton ultra-short tail swing crawler excavator with operating weight 7,990 kg (rubber tracks). Powered by ISUZU 4LE2XDPC diesel engine (41 kW/55 hp) meeting Euro 4 standards. Bucket capacity 0.28 m³.
Key Features:
- Ultra-tight tail swing radius of only 1,420 mm
- Offset boom (left 1,030 mm / right 1,340 mm)
- Maximum digging depth of 3,940 mm
- Bucket digging force 52.5 kN, arm digging force 40.0 kN
- Travel speeds 2.6/5.3 km/h, gradeability 70%
Technical Data:
Engine:
- ISUZU 4LE2XDPC, 4-cylinder turbocharged diesel, 2,179 cc, 55 hp
- Euro 4 emission class
- Hydraulic tank capacity: 36 L
Work Area:
- Maximum digging depth: 3.94 m
- Maximum digging radius: 6,110 mm
- Bucket capacity: 0.28 m³
Dimensions:
- Transport length: 6.15 m, width: 2.3 m, height: 2.62 m
- Turning radius: 1.42 m
