2023 Caterpillar 330D2L Crawler Excavator

Caterpillar 330D2L | 31.7 t

Location: Shanghai, China | Availability: 10 units available

Machine Overview:
The CAT 330D2L is a crawler excavator powered by the Cat C7.1 ACERT engine delivering 280 hp, with an operating weight of 31.7 t. It offers a bucket force of 235 kN and a digging depth of 7,390 mm.

Key Features:
- Engine: Cat C7.1 ACERT, 280 hp at 1,800 rpm, 6 cylinders, Euro 2
- Operating weight: 31.7 t
- Bucket capacity: 1.5 – 2.1 m³
- Bucket force: 235 kN; stick force: 163 kN
- Maximum digging depth: 7,390 mm; maximum reach at ground level: 10,870 mm
- Hydraulic system pressure: 35 MPa; pump flow: 2 × 220 L/min
- Fuel tank capacity: 620 L

Technical Data

Engine:
Cat C7.1 ACERT, 6 cylinders, diesel, 280 hp, Euro 2 emission class.

Hydraulic System:
Operating pressure 35 MPa, pump flow 2 × 220 L/min.

Work Area:
Maximum digging depth 7,390 mm, maximum reach at ground level 10,870 mm.

Undercarriage:
Track width 2,990 mm, chassis height 500 mm.

Attachments & Equipment:
Bucket, hydraulic hammer, counterweight.

Documentation & Compliance:
2023 year model, Euro 2.
