Caterpillar 308C Crawler Excavators for Sale

Browse 25 Caterpillar 308C Crawler Excavators machines on Machmon. Compare by model, location, and condition, then contact sellers using the enquiry options provided.

Caterpillar 308C · Crawler excavators

Caterpillar 308C

A compact radius 8 tonne class Cat midi excavator sized for urban jobsites that still need real digging reach.

Key specifications

Operating weight: approx. 7430 to 7650 kg by track and stick choice (configuration dependent); dozer blade adds approx. 380 to 390 kg
Tail swing radius: 1290 mm compact radius (CR) design
Maximum digging depth: 4140 mm with 1665 mm stick, 4690 mm with 2210 mm stick
Maximum reach at ground level: 6250 mm (medium stick) or 6770 mm (long stick)
Bucket digging force: 44 kN (SAE) with either stick
Undercarriage: Caterpillar built track-type undercarriage; 450 mm triple grouser shoes standard, 600 mm shoes or 450 mm segmented rubber track optional

Model overview

The Caterpillar 308C is an 8 tonne class midi excavator sold as the 308C CR, built with a compact tail swing radius of 1290 mm for urban and space-restricted sites. Caterpillar's specification document lists operating weights from approx. 7430 kg to 7650 kg depending on track and stick choice, a maximum digging depth of 4690 mm with the long stick, and a maximum reach at ground level of 6770 mm. It runs a 3.7 m boom with a choice of 1665 mm or 2210 mm sticks on a Caterpillar designed and built track-type undercarriage.

At a glance

GenerationC Series midi (marketed as 308C CR), mid 2000s production; succeeded by the 308D and later 308E lines, so confirm the exact series on the serial plate when comparing listings.

Stick and blade configurationTwo factory sticks (1665 mm and 2210 mm) trade breakout force against dig depth and reach, and the dozer blade is optional; verify which setup a specific machine carries.

Tracks and undercarriage wearOffered with steel triple grouser shoes or segmented rubber track; on any used unit inspect track, sprocket, idler and roller wear, since undercarriage refurbishment is a major cost item on tracked machines.

Configuration dependenceOperating weight and lift capacity vary with shoe width, stick length and blade fitment; lift charts differ between blade-up and blade-down operation.

25 machines · €14,500 - €100,000 · 2005 to 2024 · China, France, Poland

View all Caterpillar 308C listings Open filters

Specifications sourced from s7d2.scene7.com (official manufacturer page).
