2025 Kubota MB 20-SH Mini Excavator

Kubota MB 20 - SH | 2.12 Ton Mini Excavator | 1000 hours | with Warranty
Location: Poznań, Poland | Availability: Pre-order

Machine Overview:
New Kubota MB 20 - SH mini excavator with diesel power, canopy cab and 2.12 Ton formatted operating weight. Key source facts include EU Stage V emission standard, Kubota D902 E3B/K engine, hydraulic joystick control and side-swing boom.

Key Features:
- New condition, year of manufacture 2025
- Kubota D902 E3B/K diesel engine
- 3-cylinder engine with 18 hp power output
- Canopy cab model
- Hydraulic joystick control and side-swing boom
- Digging force: arm 10 kN / bucket 14 kN
- Lifting capacity: 220 kg
- Max speed: 1.8 km/h

Technical Data

Engine:
- Fuel: diesel
- Engine: Kubota D902 E3B/K
- Engine cylinders: 3
- Power output: 18 hp
- Emission class: Euro 5
- Cooling: Water-cooled
- Fuel tank: 11L

Hydraulic System:
- Hydraulic tank capacity: 19 L
- Working pressure: 16+3 MPa
- Flow rate: 15.6 + 15.6 + 7.8 L/min
- Max. working pressure: 160 + 30 Bar

Work Area:
- Max. digging depth: 2440 mm
- Max. digging height: 3485 mm
- Max. reach: 3790 mm
- Max. vertical digging depth: 1750 mm
- Max. dumping height: 2440 mm
- Grading blade lift / lowering: 160 mm / 220 mm

Dimensions / Transport:
- Length: 3.11 m
- Width: 1.25 m
- Height: 2.28 m

Undercarriage:
- Track width: 230 mm

Attachments & Equipment:
- Bucket, blade, ripper, quick coupler, front loader, winch, clamp, grapple, demolition shears, hydraulic hammer, counterweight
- 2 standard buckets: 20 cm, 40 cm, 60 cm

Documentation & Compliance:
- CE certified
- Operating manual: DE/EN/FR/etc.
- 1000-hour operating warranty

Shipping & Delivery:
- Worldwide shipping at an additional cost
